No.

Item

Unit

specifications

CNC150

（B-1）

CNC250（B-1）

CNC350

（B-1）

CNC450

（B-1）

CNC550

（B-1）

1

Max.rotation diameter on lathe’ body

mm

150

250

350

450

550

2

Max.workpiece lengt

mm

750/1000/1500

3

Max.turning diameter

mm

100

200

300

400

500

4

Spindle nose type and code

mm

A6

A6

A8

A8

A8

5

Hydraulic chuck

mm

Φ80

(4＂)

φ160

(6＂)

φ200

(8＂)

φ250

(10＂)

φ300

(12＂)

6

Front spindle bore taper

1:20

7

Spindle bore

mm

38

40

60

60

65

8

Spindle form

Programmable three gears automatic hydraulic speed change

9

Spindle frequency control speed range

rpm

20-3000

10

X/Z Rapid traverse

mm/min

20000

11

Main motor power

kW

3.7

5.5

7.5

11

15

12

X/Z-axis motor max.torque

N.m

6

10

10

10

15

13

Power specifications

V

380±10%. 50Hz±1Hz

14

Turret transfer time (one station)

s

 1.6(臥12)

15

Turret transfer repeat positioning accuracy

0.005"

16

X-axis travel

mm

100

150

200

300

350

17

Z-axis travel

mm

1100/1350/1850

18

B-axis(Tailstock) travel

mm

1100/1350/1850

19

Hydraulic turret form

Horizontal 8-station servo power turret

Horizontal 12-station servo power turret

20

Tailstock sleeve diameter/ travel

mm

45/100

50/100

65/100

70/100

80/100

21

Tailstock tapered bore taper

莫氏Morse

3#

4#

4#

4#

5#

22

Tailstock form

Electric drive

23

Tailstock sleeve form

Hydraulic drive

24

Knife handle size

mm

□16×16

□20×20

□20×20

□25×25

□25×25

25

Net weight

kg

3000

3500

4200

5000

6200

26

Size（L×W×H）

mm

2700/3000/3500×1650×1900
